NTC sensor
NTC sensor
Price：
￥0.00
★feature
1、resistance no defference
2、high exchange
3、steady and reliable
4、normal accuracy±1%～±15%
5、the max accuracy±0.1℃
6、-50℃～+125℃
7、the other parameter,size is according to customer's need
★application range
used for all kinds of temp.measure and control for electronic mechanical equipment.
★product list
type parameter | voltage | temp. range | accuracy | R-T property | power lose |
MF103H3977 | 5VDC±5％ | -40℃~100℃ | ±0.3℃ | R25=10（1±2％）kΩ B（25/85）=3977（1±1%）KΩ | ＜0.4mw/℃ |
MF103H3435 | 5VDC±5％ | -50℃~120℃ | ±0.2℃ | R25=10（1±3％）kΩ B（25/85）=3435（1±1%）KΩ | ＜0.4mw/℃ |
The electronic parameter and size above only for reference,according to custo
